Usage

Setting up a run

With imsi setup

Use imsi setup to create a run directory, obtain the model source code, and extract all required model configuration files. The setup will result in an imsi configured directory, from which futher interaction with the run is conducted.

The output of imsi setup -h:

Usage: imsi setup [OPTIONS]

  Create a run directory, obtain the model source code, and resolve the
  configuration files.

  https://imsi.readthedocs.io/en/latest/usage.html#setting-up-a-run

Options:
  --runid TEXT                    A unique identifier (<20 char, alphanumeric
                                  incl. hyphen, lower case)  [required]
  --repo TEXT                     Git repository URL or file path.  [required]
  --ver TEXT                      Version of the code to clone (clone* only).
  --exp TEXT                      Experiment name.  [required]
  --model TEXT                    Model name.  [required]
  --fetch_method [clone|clone-full|link|copy]
                                  Fetch method for source code.  [default:
                                  clone]
  --seq TEXT                      Sequencer to use, like "iss" or "maestro".
  --machine TEXT                  Machine to use.
  --flow TEXT                     Workflow to use.
  --postproc TEXT                 Postprocessing profile to use.
  --no-src-storage                Disables src_storage_dir if present in imsi-
                                  config
  --verbose                       More verbose output.
  -h, --help                      Show this message and exit.

  More information:

      valid parameter values for --model, --exp, --machine, --seq, --flow,
      --postproc are composed within the repo's imsi-config Configuration
      Files.

imsi setup creates some subdirectories for the run, including bin (for executables), and config. The config directory contains various run configuration files, including cpp directives and namelists, that have been extracted and modified according to the choice of model and experiment.

Example

>> imsi setup --repo=https://gitlab.science.gc.ca:CanESM/CanESM5 --ver=develop_canesm --exp=cmip6-piControl --model=canesm51_p1 --runid=<unique-runid>

The setup also creates a log file in the run directory (.imsi-setup.log), and a readable/writable resolved yaml state file containing the full details of the configuration options (imsi_configuration_<runid>.yaml). Additionally, it will extract the save_restart_files.sh, imsi-tmp-compile.sh, and tapeload_rs.sh scripts from the imsi-config directory within the housing model repo.

Warning

Changes to the above imsi_configuration_<runid>.yaml file are not automatically applied to your run. If you want changes to take affect, you need to run imsi config after making updates to this local yaml file.

Once you make the desired changes, if any (see here for details on making simple changes to a configuration), you then need to step through the following steps:

>> imsi build         # run the compilation tool to build your model's execs
>> imsi save-restarts # save your model's restarts
>> imsi submit        # submit your jobs!

to launch your experiment!

Interactively with imsi setup-menu

imsi setup-menu provides an interactive menu-driven interface that assembles a complete imsi setup command. Repos that appear in the setup-menu are listed based on .rc files. You can read more about these files under imsi list.

Querying available configurations

The output of imsi list -h:

Usage: imsi list [OPTIONS] [[models|experiments|compilers|machines|sequencers|
                 flows|postprocs|options|paths]]

  List available configurations for the specified component.

  If no component is provided, the list of model/experiments is rendered.

Options:
  --repo-path TEXT          Path to either a single repo or a directory of
                            repos. If not provided, examines the repos listed
                            in the .rc.
  --filter-model TEXT       Filter by model name [model/exp only].
  --filter-experiment TEXT  Filter by experiment name [model/exp only].
  --with-supports           List available supported components [model/exp
                            only].
  --plain                   Display plain text results.
  -h, --help                Show this message and exit.

  List is a simple lookup tool; it simply lists available options in imsi-
  config. Only allowable combinations of models and experiments are displayed.
  For all other components, all possible options are listed, regardless of
  current applicability.

With imsi list

Use imsi list to query the supported models, and experiments known to IMSI.

If you are already in an imsi-configured repository, the results will be based on that repository’s imsi-config directory. If you are not in an imsi-configured repository, you can: 1. Point directly to a single repository using --repo-path <path>

2. Point to a directory containing multiple repositories (each with an imsi-config) using --repo-path <directory>

3. Using IMSI_DEFAULT_CONFIG_REPOS. Users can set this value in two ways (each definition is treated additively):

   1. In $HOME/imsi.user.rc

   2. In a bash session as an environment variable, under imsi.user.rc.

Default fall-back values are packaged with imsi under the imsi/imsi.site.rc file and are site-specific.

You can further narrow the results with:

--filter-model <name> – show only configurations for a given model name

--filter-experiment <name> – show only configurations for a given experiment name

Example commands:

# List configurations from the current repository
imsi list

# List configurations from a specific repo path
imsi list --repo-path /path/to/model-repo

# List configurations from multiple repos in a directory
imsi list --repo-path /path/to/repos-dir

# Filter by model and experiment
imsi list --filter-model canesm53_b1_p1 --filter-experiment cmip6-historical

Modifying basic run parameters

There are three general methods in imsi that can be used to modify run parameters, based on the three commands: imsi config, imsi reload, and imsi set. These commands can be used in conjunction with each other and invoked repeatedly in a single run directory. Choosing which command to use the command depends on the workflow.

1. Modify the Resolved Configuration File and run imsi config

Command	>> imsi config
Steps	modify the contents of imsi_configuration_<runid>.yaml run imsi config
Purpose	Apply simple one-off changes to a run. This can be useful for development and testing purposes, such as testing the effects of simple parameter switches and running shorter simulations by changing the date settings.
Caveats	- Modifications apply to (downstream) contents, not (upstream) imsi Configuration Files. Modifications to imsi configuration yaml files are not version controlled in this workflow. - Running imsi config will modify (overwrite) contents under the /config and /sequencer folder. For some sequencers, the contents related to a run-in-progress will be preserved unless -f is used.

What does imsi config do?

imsi config propagates the current (saved) contents of the Resolved Configuration File to the run’s downstream directories, /config and /sequencer.

In other words, if you modify the contents of the Resolved Configuration File, you must then invoke imsi config to apply the changes to the run.

2. Modify the upstream imsi Configuration Files and run imsi reload

Command	>> imsi reload
Steps	modify the contents of /src/imsi-config run imsi reload
Purpose	This is the best way to create reproducible and sharable modifications to specific configurations. This is the best method for developing official modifications to models/ experiments (or other configuration), or for developers who are adding new models/experiments under the current source repository (to be used in conjunction with imsi set -s).
Caveats	- In most cases, users should set up runs with --fetch_method as clone*|copy, as a linked source may be write-restricted or unintentionally modify other linked runs. - Calling imsi reload will overwrite (manual) modifications to the Resolved Configuration File and downstream configuration folders.

What does imsi reload do?

imsi reload literally re-resolves and re-extracts the upstream imsi Configuration Files from /src/imsi-config and updates (overwrites) the Resolved Configuration File and contents in the downstream configuration folders (/config and /sequencer).

Changes applied to the run folder before invoking imsi reload will be overwritten. If changes are not made to the imsi Configuration Files, imsi reload can be used to “reset” the run folder to the configuration state resolved by the initial setup command.

Tip

When developing new configuration components under the imsi Configuration Files directory, use imsi validate before imsi reload to apply validation.

3. Swap setup parameters using imsi set --selections

Command	>> imsi set --selections <setup_param>=<value>
Steps	Run the command above. setup_param is any of the parameters in imsi setup that affect the configuration itself, and value is any corresponding key of the configuration in the imsi Configuration Files.
Purpose	Swap or “reload” parts of resolved configuration. Setting a new value to one part of configuration may also cause a re-resolving to other parts (e.g., setting to a different machine could also change the compiler configuration). This is most useful for developing new configurations under the imsi Configuration Files. See conceptual example below.
Caveats	- Similar to imsi reload, invoking this command will overwrite modifications to the Resolved Configuration File and downstream configuration folders. - If a user entered an undesired parameter upon initial setup of a run folder, this command does work to “switch” the configuration for that parameter. However, it is advisable that a new setup is run instead, to keep the development steps traceable and easily repeatable.

What does imsi set -s do?

Similiar to imsi reload, imsi set -s re-resolves and re-extracts the the upstream imsi Configuration Files from /src/imsi-config and updates (overwrites) the Resolved Configuration File and contents in the downstream configuration folders (/config and /sequencer).

The best use of imsi set -s is to apply changes while developing new configuration locally. See Using imsi set for an illustration of this workflow.

Multiple selections can also be combined together, as in:

>> imsi set -s model=model-x -s exp=exp-y

4. Apply blocks of pre-defined modifications using imsi override --option

Command	>> imsi override --option <option_block>/<option_file>
Steps	Run the command above. The options are defined in the imsi Configuration Files for the source, nominally in YAML files under imsi-config/options/<option_block>/<option_file>.
Purpose	Apply pre-defined sets of modifications to the Resolved Configuration File. The directory <option_block> and its contents can be generally thought of as common modifications to configuration that are not otherwise captured in the structured configuration system.

What does imsi override --option do?

In simple terms, imsi override --option edits the user’s Resolved Configuration File (imsi_configuration_{runid}.yaml) with changes defined in the option files. To apply the changes, users should subsequently run imsi config as they would after manually modifying the Resolved Configuration File.

Warning

Avoid editing the contents of the Run Configuration Folder directly

The contents of /config are ultimately what are intended to be used by the model. Users should not edit the contents of these files directly, since these these modifications can be overwritten by subsequent imsi commands. Some of these contents may also be used by the model at run time.

Users should use the methods described above to also ensure that their modifications are repeatable and sharable.

Using imsi set

imsi set is most appropriate for making more complex, compound modifications to configuration.

imsi set --selections is most useful for developing new sets of configurations.

For example, suppose a user sets up a run using

>> imsi setup --model=model-A --exp=exp-A ...

The configuration for the model and experiment are contained in the imsi Configuration Files for the source repository.

After initial setup, the user wants to develop a new experiment for the model, exp-B. They add a new file in their local run setup folder:

src/imsi-config
├── experiments
│   ├── imsi-exp-config_exp-A.yaml
|   └── imsi-exp-config_exp-B.yaml        <-- new
├── models
│   ├── imsi-model-config_model-A.yaml

which contains:

experiments:
  exp-B:
     supported_models:
       - model-A
     inherits_from: exp-A
     # ... more configuration for exp-B ...

To then use exp-B in their local run setup, they should then run

>> imsi set -s exp=exp-B

Any further modifications to the upstream Configuration File for exp-B can be applied by using imsi reload for simplicity thereafter.

Validating imsi configuration files with imsi validate

The user can run imsi validate during development to ensure that the contents of their configurations are valid. This command checks for schema compliance and YAML syntax. While it does not check for logical consistency of configuration contents, it can help catch common errors early in the development process.

The output of imsi validate -h:

Usage: imsi validate [OPTIONS] COMMAND [ARGS]...

  Validate imsi configuration files.

Options:
  --imsi-config-path DIRECTORY  Path to the imsi-config directory.
  -h, --help                    Show this message and exit.

Commands:
  components  Validates an experiment configuration
  experiment  Validate an experiment configuration.
  machine     Validate a machine configuration.
  model       Validate a model configuration.
  sequencing  Validate a sequencing configuration.
  syntax      Validate the syntax of the imsi configuration files.
  utilities   Validate the utility configurations.

Building run executables

With imsi build

>> imsi build

It is worth noting that all this does is call the extracted imsi-tmp-compile.sh script. Additionally, if any arguments/flags are provided after imsi build, it will send the arguments to extracted script.

For example:

>> imsi build -f -a

would send the -f -a flags to imsi-tmp-compile.sh.

Saving restarts

With imsi save-restarts

>> imsi save-restarts

Note that likewise to imsi build, imsi save-restarts just calls the extracted save_restart_files.sh script and any arguments and/or flags given to to the call are sent to the underlying script.

If the restart files you need are on tape storage, you’ll need to run the following instead:

>> imsi tapeload-rs

which is effectively a wrapper for the script tapeload_rs.sh.

Submitting the run

With imsi submit

>> imsi submit

This will interact with the sequencer in use and intelligently execute a sequencer/machine specific submission command.

Monitoring a run

While many HPC users will be accustomed to monitoring simulations/jobs via sequencer specific tools (xflow for maestro users) or job-scheduler commands like qstat or squeue. Provided the sequencer being used support this, imsi also provides a method for monitoring the status of a simulation (or ensemble of simulations):

For maestro sequencers with imsi status

This CLI command ultimately interfaces with the sequencer caps, so the behaviour of this command is sequencer specific. To run the status command, do:

>> imsi status

For maestro, will result in:

which will tell you all the maestro experiments running, and within each experiment, it will show you which jobs are currently queued, running, failed, completed, or in maestro’s “catchup” status.

iss

This feature has not yet been implemented for iss - if you execute this command while using iss, you will see a NotImplementedError raised.
